Frame Material: 16 gauge cold rolled steel.
Frame Depth: 2-1/2”
Flange: Exposed (FD) – 1″
Drywall Bead (FDW) – 1″
Plaster Bead (FDP)- 1-3/8″
Door Panel Material: 20 ga. cold rolled steel
Standard Finish: White powder coat
Insulation: 2” mineral wool
Hinge: Continuous hinge
Closer: Panel automatically closes and latches from an open position of 90° as required by NFPA 80
Latch: Universal lock with ring and key
UL Listed and Labeled: Vertical – 1-1/2 hour UL“B” label in a 2 hour fire barrier.
Intertek Warnock Hersey Listed and Labeled: Horizontal – 3 hour non-combustible rating or 1 hour combustible rating.
