Product Specifications
Material: 1-⅝” x .065″ (16 gauge) galvanized steel tubing
Bracket Material: 2″ x 2″ x .048″ (18 gauge) square galvanized steel tubing
Finish: Yellow powder coat
Hinges: Steel, adjustable spring hinges
Gate: Self-closing, self-latching with telescoping size adjustment
Latch: Steel, black powder coat pin hooks around gravity latch catch
Hardware: Black plastic tubing caps and zinc-plated steel hardware
Performance: 200 lbs with maximum 3″ deflection per OSHA 1910.29, ANSI 1264.4 and 50 pounds per linear foot per 2024 IBC 1607.9 (ASCE 7)
