Product Specifications
Material: 6063-T5 Aluminum
Standard Finish: Mill
Fasteners: Zinc plated steel #10 x 1-1/2″ Philips flat head wood screws, use 1/8″ drill bit (12″ hole spacing)
Sizes:
Minimum: 6″
Maximum: 186″
Thresholds 47″ and under include 1/2″ extra for fitting. 48″ and over include 1″ extra for fitting. Thresholds 120″ and over are supplied without holes.
Fire Rated: UL Classified per UL10B, CAN/ULC-S104, UL10C for use on listed steel frames and/or classified hollow metal and steel covered composite type fire doors rated 3 hours, wood composite to 1-1/2 hours, wood core type rated 20 min without hose stream.
