Product Specifications
Material: 6063-T5 Aluminum
Standard Finish: Mill
Fasteners: Zinc-plated steel #6 x 5/8″ Philips pan head self-tapping sheet metal screws, use 7/64″ drill bit (6″ hole spacing
Sizes:
Minimum: 6″
Maximum: 163″
Fire Rated: UL Classified per UL10B, CAN/ULC-S104, UL10C for use on listed steel frames and/or classified hollow metal and steel covered composite type fire doors rated 3 hours, wood composite to 1-1/2 hours, wood core type rated 20 min without hose stream.
