Material: 18 gauge cold rolled steel. VLFSG has 12 gauge security grille.
Standard Finish: Mineral bronze powder coat
Fasteners: Flathead Phillips head thrubolts to match finish
Size: Min: 4” x 4” – Max and Round: see submittals.
Glazing Thickness: 3/16″ – 1-11/16″ depending on standard or IG frame.
Door: 1″ to 3″ depending on frame.
Options: Round frame, stainless steel, galvannealed steel, zinc-plated steel, mullions, UL10C, PAK combination with glazing.
FIRE RATINGS: UL listed and labeled to ANSI/UL10B, UL10C and ULC-S104 when installed in properly rated and approved door. Ratings up to 3 hours, depending on the application, glazing and size. Optional Intertek Warnock Hersey fire rated label. Ratings up to 1-½ hours, depending on door type, application glazing and size.
See Options & Accessories tab for PAK Submittals.
